| TYPE | SWL (t) | Dead weight (Kg) |
Volu me (m3) |
Dia. Of wire rope (mm) |
Pulley | Overall size锛坢m锛? | |||||||
| Dia | Rate | A | B | C | D | E | F | G | |||||
| RNT12.5-1.8-4300 | 12.5 | 4760 | 4.3 | 24 | 450 | 3 | 3080 | 2980 | 2240 | 2920 | 2420 | 6870 | 6990 |
| RNT16.0-1.8-5400 | 16.0 | 6180 | 5.4 | 26 | 500 | 3 | 3360 | 3220 | 2500 | 3180 | 2500 | 7430 | 7570 |
| RNT20.0-1.8-6700 | 20.0 | 7830 | 6.7 | 28 | 560 | 3 | 3600 | 3480 | 2640 | 3400 | 2700 | 7920 | 8050 |
| RNT25.0-1.8-8500 | 25.0 | 9630 | 8.5 | 32 | 630 | 3 | 4060 | 3940 | 2880 | 3710 | 3000 | 8750 | 8860 |
| RNT32.0-1.8-11500 | 32.0 | 11140 | 11.5 | 36 | 710 | 3 | 4620 | 4240 | 3310 | 4160 | 3260 | 10340 | 10750 |
| RNT12.5-1.8/2.6-4300/2900 | 16.0 | 4880 | 4.3/2.9 | 24 | 450 | 3 | 3080 | 2980 | 2240 | 2920 | 2420 | 6870 | 6990 |
| RNT16.0-1.8/2.6-5400/3700 | 16.0 | 6280 | 5.4/3.7 | 26 | 500 | 3 | 3360 | 3220 | 2500 | 3180 | 2500 | 7430 | 7570 |
| RNT20.0-1.8/2.6-6700/4600 | 20.0 | 7920 | 6.7/4.6 | 28 | 560 | 3 | 3600 | 3480 | 2640 | 3400 | 2700 | 7920 | 8050 |
| RNT25.0-1.8/2.6-8500/5700 | 25.0 | 9700 | 8.5/5.7 | 32 | 630 | 3 | 4060 | 3940 | 2880 | 3710 | 3000 | 8750 | 8860 |
| RNT32.0-1.8/2.6-11500/8000 | 32.0 | 11200 | 11.5/8.0 | 36 | 710 | 3 | 4620 | 4240 | 3310 | 4160 | 3260 | 10340 | 10750 |
| RNT20.0-1.0/1.8-10000/6600 | 20.0 | 8120 | 10.0/6.6 | 28 | 560 | 3 | 3910 | 3770 | 2950 | 3920 | 3000 | 8220 | 8370 |
| RNT25.0-1.8/1.8-12000/8300 | 25.0 | 9960 | 12.0/8.3 | 32 | 630 | 3 | 4300 | 4160 | 3140 | 4120 | 3300 | 8990 | 9020 |
