Type（SHNC） |
Density (t/ m3) |
Dead weight (Kg) |
SWL (t) |
Volume (m3) |
pulley |
Wire rope |
Overall size（mm） |
|||||||
|
Dia. |
Rate |
Dia. |
Length |
stroke |
A |
B |
C |
D |
E |
|||||
|
SHNC10.0-2.6-2600 |
2.6 |
3240 |
10.0 |
2.60 |
450 |
2 |
22 |
13.5 |
4850 |
3610 |
3850 |
2240 |
3760 |
2300 |
|
SHNC12.5-2.6-3200 |
2.6 |
4180 |
12.5 |
3.20 |
500 |
2 |
24 |
14.7 |
5110 |
3940 |
4180 |
2320 |
4080 |
2400
|
|
SHNC16.0-2.6-4100
|
2.6
|
5340
|
16.0
|
4.10
|
560
|
2
|
26
|
16.3
|
5600
|
4370
|
4630
|
2360
|
4510
|
2460
|
|
SHNC20.0-2.6-5200
|
2.6
|
6480
|
20.0
|
5.20
|
630
|
2
|
28
|
18.5
|
6220
|
4890
|
5040
|
2570
|
5050
|
2660
|
|
SHNC25.0-2.6-6500
|
2.6
|
8100
|
25.0
|
6.50
|
630
|
2
|
32
|
19.0
|
6350
|
5010
|
5230
|
2780
|
5240
|
2750
|
|
SHNC32.0-2.6-8200
|
2.6
|
10680
|
32.0
|
8.20
|
710
|
2
|
36
|
20.8.
|
7080
|
5580
|
5830
|
3020
|
5740
|
2920
|
|
SHNC40.0-2.6-10200
|
2.6
|
13480
|
40.0
|
10.20
|
800
|
2
|
40
|
23.5
|
7980
|
6230
|
6520
|
3280
|
6350
|
3050
|
|
SHNC50.0-2.6-12700
|
2.6
|
16980
|
50.0
|
12.70
|
900
|
2
|
44
|
25.0
|
8650
|
6640
|
7010
|
3560
|
6680
|
3240
|
|
SHNC63.0-2.6-16000
|
2.6
|
21400
|
63.0
|
16.00
|
1000
|
2
|
48
|
29.0
|
10390
|
7620
|
7950
|
3840
|
7620
|
3470
|
|
|
||||||||||||||
|
SHNC10.0-3.2-2150
|
3.2
|
3120
|
10.0
|
2.15
|
450
|
2
|
22
|
14.0
|
4850
|
3610
|
3850
|
2240
|
3760
|
1900
|
|
SHNC12.5-3.2-2650
|
3.2
|
4020
|
12.5
|
2.65
|
500
|
2
|
24
|
15.0
|
5110
|
3940
|
4180
|
2320
|
4080
|
1980
|
|
SHNC16.0-3.2-3400
|
3.2
|
5120
|
16.0
|
3.40
|
560
|
2
|
26
|
16.3
|
5600
|
4370
|
4630
|
2360
|
4510
|
2040
|
|
SHNC20.0-3.2-4250
|
3.2
|
6400
|
20.0
|
4.25
|
630
|
2
|
28
|
18.5
|
6220
|
4890
|
5040
|
2570
|
5050
|
2170
|
|
SHNC25.0-3.2-5350
|
3.2
|
7880
|
25.0
|
5.35
|
630
|
2
|
32
|
19.0
|
6350
|
5010
|
5230
|
2780
|
5240
|
2260
|
|
SHNC32.0-3.2-6700
|
3.2
|
10560
|
32.0
|
6.70
|
710
|
2
|
36
|
20.8.
|
7080
|
5580
|
5830
|
3020
|
5740
|
2380
|
|
SHNC40.0-3.2-8400
|
3.2
|
13120
|
40.0
|
8.40
|
800
|
2
|
40
|
23.5
|
7980
|
6230
|
6520
|
3280
|
6350
|
2510
|
|
SHNC50.0-3.2-10400
|
3.2
|
16720
|
50.0
|
10.40
|
900
|
2
|
44
|
25.0
|
8650
|
6640
|
7010
|
3560
|
6680
|
2660
|
|
SHNC63.0-3.2-13200
|
3.2
|
20760
|
63.0
|
13.20
|
1000
|
2
|
48
|
29.0
|
10390
|
7620
|
7950
|
3840
|
7620
|
2860
|
 |
 |
 |
